S22MD1V

S22MD1V, Photothyristor Coupler, DIP, 520mA, 6V, Sharp Electrionic Components

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.27~0.31 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 500 :	0.31 / Piece
501 ~ 2000 :	0.29 / Piece
2001 ~ 5000 :	0.27 / Piece

PartNumber:: S22MD1V

Brand:: Sharp Electrionic Components - Sharp | Pack: DIP | D/C: 08+

Availability:: Supply Ability: 2/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. yoyo's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-01-06

From Other Seller

Part Number:S22MD1V
US $0.27 - 0.31
Quantity:

piece

Product Summary

The S22MD1V is a Photothyristor Coupler. The applications of the S22MD1V include ON-OFF operation for a low power load, For triggering high power thyristor and triac.

Parametrics

S22MD1V absolute maximum ratings: (1)Forward current, IF: 50 mA; (2)Reverse voltage, VR: 6 V; (3)RMS ON-state current, IT: 200mA; (4)Peak one cycle surge current, Isurge: 2 A; (5)Repetitive peak OFF-state voltage, VDRM: 600 V; (6)Repetitive peak reverse voltage VRRM 600 - V; (7)Isolation voltage Viso: 5000Vrms; (8)Operating temperature, Topr: -30 to +100℃; (9)Storage temperature, Tstg: -55 to +125℃; (10)Soldering temperature, Tsol: 260℃.

Features

S22MD1V features: (1)High repetitive peak OFF-state voltage (VDRM: MIN. 600V); (2)Low trigger current (IFT: MAX. 10mA at RG = 20kW ); (3)High isolation voltage between input and output; (4)Recognized by UL, file NO. 64380.
