AMP04F

instrumentation amplifier, ±18V, 150 μV, SOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $3.40~4.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
5 ~ 50 :	4.00 / Piece
51 ~ 100 :	3.70 / Piece
101 ~ 300 :	3.40 / Piece

PartNumber:: AMP04F

Brand:: Analog Devices - ADI | Pack: SOP | D/C: 09+

Availability:: Supply Ability: 2/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. yoyo's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-02-18

From Other Seller

Part Number:AMP04F
US $3.40 - 4.00
Quantity:

piece

Product Summary

The amp04f is a single-supply instrumentation amplifier designed to work over a +5 volt to ±15 volt supply range. The The amp04f offers an excellent combination of accuracy, low power consumption, wide input voltage range, and excellent gain performance. In addition to being easy to use, the AMP04 draws only 700μA of supply current. The amp04f is specified over the extended industrial (-40°C to +85°C) temperature range. Applications of the amp04f include: Strain Gages, Thermocouples, RTDs, Battery Powered Equipment, Medical Instrumentation, Data Acquisition Systems, PC Based Instruments, Portable Instrumentation.

Parametrics

amp04f absolute maximum ratings: (1) Supply Voltage: ±18V; (2) Common-Mode Input Voltage: ±18V; (3) Differential Input Voltage: 36V; (4) Output Short-Circuit Duration to GND: Indefinte; (5) Storage Temperature Range Z Package: -65°C to +175°C, P, S Package: -65°C to +150°C; (6) Operating Temperature Range: -40°C to +85°C; (7) Lead Temperature Range (Soldering, 60 sec) : +300°C; (8) Junction Temperature Range: Z Package: -65°C to +175°C, P, S Package: -65°C to +150°C.

Features

amp04f features: (1) Single Supply Operation; (2) Low Supply Current: 700 μA max; (3) Wide Gain Range: 1 to 1000; (4) Low Offset Voltage: 150 μV max; (5) Single-Resistor Gain Set; (6) 8-Pin Mini-DIP and SO packages.
