2SK2996

2SK2996, Silicon N Channel MOS Type DC-DC Converter, TO, 600V, 10A, Sanken electric

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.40~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
10 ~ 50 :	0.50 / Piece
51 ~ 200 :	0.45 / Piece
201 ~ 1000 :	0.40 / Piece

PartNumber:: 2SK2996

Brand:: Sanken electric - Sanken | Pack: TO | D/C: 09+

Availability:: Supply Ability: 2/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. yoyo's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-01-21

From Other Seller

Part Number:2SK2996
US $0.40 - 0.50
2SK2996 Band new and orginal

US $1.00 - 1.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The 2SK2996 is a Silicon N Channel MOS Type DC-DC Converter, Relay Drive and Motor Drive Applications.

Parametrics

2SK2996 absolute maximum ratings: (1)Drain.source voltage, VDSS: 600 V; (2)Drain.gate voltage (RGS = 20 kΩ), VDGR: 600 V; (3)Gate.source voltage, VGSS: ±30 V; (4)Drain current, DC (Note 1), ID: 10A; Pulse (Note 1), IDP: 30A; (5)Drain power dissipation (Tc = 25℃), PD: 45 W; (6)Single pulse avalanche energy(Note 2), EAS: 252 mJ; (7)Avalanche current, IAR: 10 A; (8)Repetitive avalanche energy (Note 3), EAR: 4.5 mJ; (9)Channel temperature, Tch: 150℃; (10)Storage temperature range, Tstg: -55 to 150℃.

Features

2SK2996 features: (1)Low drain.source ON resistance : RDS (ON) = 0.74 Ω (typ.); (2)High forward transfer admittance : |Yfs| = 6.8 S (typ.); (3)Low leakage current : IDSS = 100 μA (max) (VDS = 600 V); (4)Enhancement mode : Vth = 2.0~4.0 V (VDS = 10 V, ID = 1 mA).
