Product Summary

The 2N6545 is a NPN silicon power transistor, which is designed for high-voltage, high-speed, power switching inductive circuits where fall time is critical.

Parametrics

Absolute maximum ratings: (1)collector-emitter voltage: 400V; (2)collector-emitter voltage: 850V; (3)collector-base voltage: 9.0 V; (4)collector current-continuous: 8.0 A; (5)collector current-peak: 16 A; (6)base current-continuous: 8.0 A; (7)emitter current-continuous: 16 A; (8)emitter current-peak: 32 A; (9)total power dissipation @ Tc=25℃: 125 W; (10)derate above 25℃: 0.714 W/℃.

Features

Features: reversed biased SOA with inductive loads switching times with inductive loads saturation voltages, leakage currents.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
2N6545
2N6545

Central Semiconductor

Transistors Bipolar (BJT) NPN Power SW

Data Sheet

0-1: $2.48
1-25: $2.41
25-100: $2.31
100-250: $2.22
