BD9886FV

BD9886FV, DC-AC Inverter Control IC, tssop28, 15V, 850mW, Rohm Semiconductor

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.75~0.92 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
10 ~ 50 :	0.92 / Piece
51 ~ 100 :	0.84 / Piece
101 ~ 500 :	0.75 / Piece

PartNumber:: BD9886FV

Brand:: Rohm Semiconductor - Rohm | Pack: TSSOP | D/C: 09+

Availability:: Supply Ability: 2/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. yoyo's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-01-25

From Other Seller

Part Number:BD9886FV
US $0.75 - 0.92
Quantity:

piece

Product Summary

The BD9886FV is a DC-AC Inverter Control IC.

Parametrics

BD9886FV absolute maximum ratings: (1)Supply voltage, VCC: 15V; (2)Operating temperature range, Topr: -40 to 90℃; (3)Storage temperature range, Tstg: -55 to 125℃; (4)Power dissipation, PD: 850mW; (5)Maximum junction temperature, TJmax: +125℃.

Features

BD9886FV features: (1)2ch control with push-pull; (2)Lamp current and voltage sense feed back control; (3)Sequencing easily achieved with soft start control; (4)Short circuit protection with timer latch; (5)Under voltage lock out; (6)Short circuit protection with over voltage; (7)Mode-selectable the operating or stand-by mode by stand-by pin; (8)Synchronous operating the other BD9886FV IC’s; (9)BURST mode controlled by PWN and DC input.
