LT1084CP

LT1084CP, Low Dropout Positive Fixed Regulator, TO, 30V, 9.5A, Linear Technology

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.83~1.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
10 ~ 50 :	1.00 / Piece
51 ~ 100 :	0.91 / Piece
101 ~ 500 :	0.83 / Piece

PartNumber:: LT1084CP

Brand:: Linear Technology - Linear | Pack: TO | D/C: 07+

Availability:: Supply Ability: 2/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. yoyo's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-01-25

From Other Seller

Part Number:LT1084CP
US $0.83 - 1.00
Quantity:

piece

Product Summary

The LT1084CP is a positive adjustable regulator designed to provide 3A, 5A and 7.5A with higher efficiency than currently available devices. All internal circuitry is designed to operate down to 1V input to output differential and the dropout voltage is fully specified as a function of load current. Dropout is guaranteed at a maximum of 1.5V at maximum output current, decreasing at lower load currents. On-chip trimming adjusts the output voltage to 1%. Current limit is also trimmed, minimizing the stress on both the regulator and power source circuitry under overload conditions. The applications of the LT1084CP include High Efficiency Linear Regulators, Post Regulators for Switching Supplies, Constant Current Regulators, Battery Chargers.

Parametrics

LT1084CP absolute maximum ratings: (1)Power Dissipation: Internally Limited; (2)Input Voltage (Note 1): 30V; (3)Operating Input Voltage 3.3V, 3.6V Devices: 20V; 5V Devices: 20V; 12V Devices: 25V; (4)Operating Junction Temperature Range, “C” Grades: Control Section: 0℃ to 125℃; Power Transistor: 0℃ to 150℃; (5)“M” Grades, Control Section: -55℃ to 150℃; Power Transistor: -55℃ to 200℃; Storage Temperature Range: -65℃ to 150℃; Lead Temperature (Soldering, 10 sec): 300℃.

Features

LT1084CP features: (1)Three-Terminal 3.3V, 3.6V, 5V and 12V; (2)Output Current of 3A, 5A or 7.5A; (3)Operates Down to 1V Dropout; (4)Guaranteed Dropout Voltage at Multiple Current Levels; (5)Line Regulation: 0.015%; (6)Load Regulation: 0.1%; (7)100% Thermal Limit Functional Test; (8)Adjustable Versions Available.
