Product Summary
The SG1731J is a completely self-contained 5V regulator. Designed to provide local regualtion at currents up to 1A for digital logic cards, this device is available in the hermetic TO-3, TO-66, TO-39 and hermetic and plastic TO-220.
Parametrics
SG1731J absolute maximum ratings: (1)Input Voltage: 35V; (2)Power Dissipation: Internally Limited; (3)Storage Temperature Range: -65°C to 150°C; (4); (5)Thermal Resistance-Junction to Case: 3.0°C/W; (6)Thermal Resistance-Junction to Ambient: 35°C/W.
Features
SG1731J features: (1)Fully compatible with TTL and DTL; (2)Output current in excess of 1A; (3)Internal thermal overload protection; (4)No additional external components; (5)Bandgap reference voltage; (6)Foldback current limiting.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 SG1731J |
Other |
|
Data Sheet |
Negotiable |
|
||||
|
SG1731J/883B |
Other |
|
Data Sheet |
Negotiable |
|
||||
