Product Summary
The 89C51CC01UA is the first member of the CANary family of 8-bit microcontrollers dedicated to CAN network applications. Besides the full CAN controller 89C51CC01UA provides 32K Bytes of Flash memory ncluding In-System-Programming (ISP) , 2K Bytes Boot Flash Memory, 2K Bytes EEPROM and 1.2-Kbyte RAM. Special attention is paid to the reduction of the electro-magnetic emission of
89C51CC01UA.
Parametrics
Ambiant Temperature Under Bias: I=industrial: -40°C to 85°C; (2) Storage Temperature: -65°C to +150°C; (3) Voltage on Vcc from Vss: -0.5V to +6V; (4) Voltage on Any Pin from Vss: -0.5V to Vcc +0.2V; (5) Power Dissipation: 1W.
Features
89C51CC01UA features: (1) 80C51 Core Architecture; (2) 256 Bytes of On-chip RAM; (3) Boot Code Section with Independent Lock Bits; (4) 2K Bytes of On-chip Flash for Bootloader; (5) 14-sources 4-level Interrupts; (6) Double Data Pointer; (7) Time Triggered Communication; (8) Power Saving Modes: Idle Modle, Power-down Mode.
Diagrams
