LM311M

LM311M, Voltage Comparator, sop8, 36V, 150nA, National Semiconductor

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.17~0.20 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
50 ~ 100 :	0.20 / Piece
101 ~ 300 :	0.18 / Piece
301 ~ 600 :	0.17 / Piece

PartNumber:: LM311M

Brand:: National Semiconductor - NS | Pack: SOP | D/C: 08+

Availability:: Supply Ability: 2/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. yoyo's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-01-26

From Other Seller

Part Number:LM311M
US $0.17 - 0.20
Quantity:

piece

Product Summary

The LM311M is a voltage comparator that has input currents nearly a thousand times lower than devices like the LM106 or LM710. The LM311M is also designed to operate over a wider range of supply voltages: from standard ±15V op amp supplies down to the single 5V supply used for IC logic. Its output is compatible with RTL, DTL and TTL as well as MOS circuits. Further, the LM311M can drive lamps or relays, switching voltages up to 50V at currents as high as 50 mA. Both the inputs and the outputs of the LM311M can be isolated from system ground, and the output can drive loads referred to ground, the positive supply or the negative supply.

Parametrics

LM311M absolute maximum ratings: (1)Total Supply Voltage (V84): 36V; (2)Output to Negative Supply Voltage (V74): 50V; (3)Ground to Negative Supply Voltage (V14): 30V; (4)Differential Input Voltage: ±30V; (5)Input Voltage (Note 4): ±15V; (6)Output Short Circuit Duration: 10 sec; (7)Operating Temperature Range: -25℃ to 85℃; (8)Lead Temperature (Soldering, 10 sec): 260℃; (9)Voltage at Strobe Pin: V+ -5V.

Features

LM311M features: (1)Operates from single 5V supply; (2)Input current: 150 nA max. over temperature; (3)Offset current: 20 nA max. over temperature; (4)Differential input voltage range: ±30V; (5)Power consumption: 135 mW at ±15V.
