Product Summary
The LTC1334CSW is a low power CMOS bidirectional transceiver featuring two reconfigurable interface ports. It can be configured as two RS485 differential ports, as two dual RS232 single-ended ports or as one RS485 differential port and one dual RS232 single-ended port.
Parametrics
LTC1334CSW absolute maximum ratings: (1)Supply Voltage (VCC): 6.5V; (2); (3)Input Voltage Drivers:– 0.3V to (VCC + 0.3V); (4)Input Voltage Receivers:– 25V to 25V; (5); (6)Output Voltage Drivers:– 18V to 18V; (7)Output Voltage Receivers:– 0.3V to (VCC + 0.3V).
Features
LTC1334CSW features: (1)Four RS232 Transceivers or Two RS485; (2)Transceivers on One Chip; (3)Operates from a Single 5V Supply; (4)Withstands Repeated ±10kV ESD Pulses; (5)Uses Small Charge Pump Capacitors: 0.1mF; (6)Low Supply Current: 8mA Typical; (7)10mA Supply Current in Shutdown; (8)Self-Testing Capability in Loopback Mode; (9)Power-Up/Down Glitch-Free Outputs; (10)Driver Maintains High Impedance in Three-State,Shutdown or with Power Off.
