STW18NK80Z

zener-protected super mesh power mosfet, 800V, 19V, TO

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.87~1.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
10 ~ 50 :	1.00 / Piece
51 ~ 200 :	0.92 / Piece
201 ~ 1000 :	0.87 / Piece

PartNumber:: STW18NK80Z

Brand:: STMicroelectronics - ST | Pack: TO | D/C: 09+

Availability:: Supply Ability: 2/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. yoyo's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-01-29

From Other Seller

Part Number:STW18NK80Z
US $0.87 - 1.00
Quantity:

piece

Product Summary

The STW18NK80Z zener-protected super mesh power mosfet. The STW18NK80Z is obtained through an extreme optimization of ST well established strip-based PowerMESH layout. In addition to pushing on-resistance significantly down, specialcare of the STW18NK80Z is taken to ensure a very good dv/dt capavility for the most demanding applications. Applications of the STW18NK80Z include: high current, high speed switching, ideal for off-line power supplies.

Parametrics

STW18NK80Z absolute maximum ratings: (1) Drain-source Voltage (VGS=0) VDS: 800V; (2) Drain-gate Voltage (RGS =20kΩ) VDGR: 800V; (3) Gate-source Voltage VGS: ±30V; (4) Drain Current(continuous)at T =25°C ID=19A; (5) DrainCurrent(continuous) at TC=100μID: 12A; (6) Drain Current(pulsed) IDM: 76A; (7) Total Dissipationat TC=25°C, PTOT: 350W; (8) Derating Factor: 2.4W/°C; (9) Gate source ESD(HBMC=100pF,R=1.5KΩ) : 6000V; (10) Peak Diode Recovery voltage slope dv/dt: 4.5V/ns; (11) Operating Junction Temperature, Storage Temperature Tj, Tstg: -55 to 150°C.

Features

STW18NK80Z features: (1) typical (on) =34Ω; (2) extremely high dv/dt capacity; (3) 100% avalanche tested; (4) gate charge minized; (5) very low intrinsic capaciances; (6) very good manufacturing repeatiblity.
