2SA1492

2SA1492, Silicon PNP Epitaxial Planar Transistor, TO-3P, -180V, -15A, 130W, Sanken electric

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.66~0.84 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
10 ~ 50 :	0.84 / Piece
51 ~ 200 :	0.75 / Piece
201 ~ 1000 :	0.66 / Piece

PartNumber:: 2SA1492

Brand:: Sanken electric - Sanken | Pack: TO | D/C: 09+

Availability:: Supply Ability: 2/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. yoyo's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-01-29

From Other Seller

Part Number:2SA1492
US $0.66 - 0.84
Quantity:

piece

Product Summary

The 2SA1492 is a Silicon PNP Epitaxial Planar Transistor. It is used in Audio and General Purpose.

Parametrics

2SA1492 absolute maximum ratings: (1)VCBO: -180V; (2)VCEO: -180V; (3)VEBO: -6V; (4)IC: -15A; (5)IB: -4A; (6)PC: 130(TC=25℃)W; (7)Tj: 150℃; (8)Tstg: -55 to +150℃.

Features

2SA1492 features: (1)ICBO: -100max μA; (2)IEBO: -100max μA; (3)V(BR)CEO: -180min V; (4)hFE: 50min; (5)VCE(sat): -2.0max V; (6)fT: 20typ MHz; (7)COB: 500typ pF.
