L9616D

L9616D, high speed CAN bus transceiver, sop8, -0.3 to 7 V, -3 to 5 mA, STMicroelectronics

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.38~0.42 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
50 ~ 100 :	0.42 / Piece
101 ~ 300 :	0.40 / Piece
301 ~ 600 :	0.38 / Piece

PartNumber:: L9616D

Brand:: STMicroelectronics - ST | Pack: SOP | D/C: 09+

Availability:: Supply Ability: 2/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. yoyo's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-01-26

From Other Seller

Part Number:L9616D
US $0.38 - 0.42
Quantity:

piece

Product Summary

The L9616D is a bidirectional transceiver for signal conditioning and processing in connection with a CAN controller. Data rates of up to 1MEGABAUD are supported using either shielded or nonshielded pair of lines.

Parametrics

L9616D absolute maximum ratings: (1)VS, Supply Voltage: -0.3 to 7 V; (2)VC_H, VC_L, Bus Voltage at C_H, C_L (VS 0 to 5.5V): -5 to 36 V; (3)IC_H, IC_L, Off State Leakage Current at C_H, C_L ( VS =0 to 5.5V, VC_H = -5 to 36V, VC_L = -5 to 36): -3 to 5 mA; (4)VDC, DC Voltage at TXO, ASC (VS 0 to 5.5V): GND -0.3 to VS +0.3 V; (5)IRXO, Output Current at RXO (VS 0 to 5.5V): -0.3 to 1 mA; (6)Tstg, TJ, Storage and Junction Temperature Range: -40 to 150℃; (7)Top, Operating Temperature Range: -40 to 125℃.

Features

L9616D features: (1)L9616 meets iso/dis 11898 up to 1megabaud transmitter, generation of differential output; (2)signals; short circuit protected from -5v to 36v, detection & shutdown; slope control to reduce rfi and emi; two states adjustable slope control (≤1megabaud/≤250kbaud); (3)receiver, differenzial input with high; interference suppression, common mode input voltage range; (4)(vcom) from -2v to vs+3v; (5)esd protection level up to 4kv; (6)package: so-8.
