LM2678S-5.0

step-down voltage regulator, 5A, 8V to 40V, TO

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.40~1.70 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
10 ~ 200 :	1.70 / Piece
201 ~ 500 :	1.50 / Piece
501 ~ 1500 :	1.40 / Piece

PartNumber:: LM2678S-5.0

Brand:: NEC - Nec | Pack: TO | D/C: 09+

Availability:: Supply Ability: 2/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. yoyo's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-03-28

From Other Seller

Part Number:LM2678S-5.0
US $1.40 - 1.70
Quantity:

piece

Product Summary

The LM2678S-5.0 regulator is a monolithic integrated circuit which provides all of the active functions for a ep-down(buck switching regulator capable of driving up to 5A loads with excellent line and load regulation characteristics. The LM2678S-5.0 also has built in thermal shutdown, current limiting and an ON/OFF control input that can power down the regulator to a low 50μA quiescent current standby condition. Applications of the LM2678S-5.0 include: Simple to design, high efficiency ( 90%) step-down switching regulators, Efficient system pre-regulator for linear voltage regulators, Batterychargers.

Parametrics

LM2678S-5.0 absolute maximum ratings: (1) Input Supply Voltage: 45V; (2) ON/OFF Pin Voltage: -0.1V to 6V; (3) Switch Voltage to Ground: -1V to Vin; (4) Boost Pin Voltage: Vsw + 8V; (5)Feedback Pin Voltage: -0.3V to 14V; (6) Power Dissipation: Internally Limited; (7) ESD: 2kV; (8) Storage Temperature Range: -65°C to 150°C; (9) Soldering Temperature Wave: 4 sec, 260°C, Infared: 10 sec, 240°C, Vapor Phase: 75 sec, 219°C. (10) Supply Voltage: 8V to 40V; (11) )Junction Temperature Range(Tj) : -40°C to 125°C.

Features

LM2678S-5.0 features: (1) Efficiency up to 92%; (2) Simple and easy to design with(using off-the-shelf externalcomponents) ; (3) 120mΩ output switch; (4) 3.3V,5V and 12V fixed output and adjustable(1.2V to 37V)versions; (5) 50μA standby current when switched OFF; (6) ±2% maximum output tolerance over full line and load conditions; (7) Wide input voltage range: 8Vto40V; (8) 260KHz fixed frequency internal oscillator; (9) -40 to +125°C operating junction temperature range.
