TDA4863AJ

TDA4863AJ, deflection booster, zip7, -40V, ±1.8 A, NXP Semiconductors

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.34~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
10 ~ 50 :	0.50 / Piece
51 ~ 200 :	0.42 / Piece
201 ~ 500 :	0.34 / Piece

PartNumber:: TDA4863AJ

Brand:: NXP Semiconductors - nxp | Pack: ZIP | D/C: 02+

Availability:: Supply Ability: 2/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. yoyo's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-01-21

From Other Seller

Part Number:TDA4863AJ
US $0.34 - 0.50
TDA4863AJ PHILIPS ZIP-7 100% original & new

US $1.00 - 1.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The TDA4863AJ is a deflection booster for use in vertical deflection systems for frame frequencies up to 200 Hz. The TDA4863AJ needs a separate flyback supply voltage, so the supply voltages are independently adjustable to optimize power consumption and flyback time. For the TDA4863AJ the flyback supply voltage will be generated internally by doubling the supply voltage and therefore a separate flyback supply voltage is not needed. Both circuits provide differential input stages and fit well with the TDA485X monitor deflection controller family.

Parametrics

TDA4863AJ absolute maximum ratings: (1)VP1 supply voltage 1: - 40 V; (2)VP2 supply voltage 2: - 60 V; (3)VFB flyback supply voltage of TDA4863J: - 60 V; (4)VP3 flyback generator output voltage of TDA4863AJ (pin 2) 0 VP1: + 3 V; (5)Vi(6,7) input voltage on pins 6 and 7: VP1 V; (6)Vo(5) output voltage on pin 5: 62 V; (7)IP2 supply current 2 (pin 3): ±1.8 A; (8)Io(5) output current (pin 5) note 1: ±1.8 A; (9)I2 flyback current on pin 2: ±1.8 A; (10)Tstg storage temperature: -25 to +150 ℃; (11)Tamb ambient temperature: -20 to +75 ℃; (12)Tj junction temperature: - 150 ℃; (13)Ves electrostatic discharge voltage on all pins: -300 to +300 V.

Features

TDA4863AJ features: (1)Power amplifier with differential inputs; (2)Output current up to 3 A (p-p); (3)High vertical deflection frequency up to 200 Hz; (4)High linear sawtooth signal amplification; (5)Flyback generator.
