Product Summary

The 40T03GP is an Advanced Power MOSFET from APEC, which provides the designer with the best combination of fast switching, ruggedized device design, low on-resistance and cost-effectiveness. The TO-252 package of the 40T03GP is universally preferred for all commercialindustrial surface mount applications and suited for low voltage applications such as DC/DC converters. And the 40T03GP is available for low-profile applications.

Parametrics

40T03GP absolute maximum ratings: (1)Drain-Source Voltage: 30V; (2)Drain-Source Voltage: ±25V; (3)Continuous Drain Current: 28A; (4)Continuous Drain Current: 24A; (5)Pulsed Drain Current: 95A; (6)Total Power Dissipation: 31.25W; (7)Linear Derating Factor:0.25W/℃; (8)Storage Temperature Range: 155 to 150℃; (9)Operating Junction Temperature Range: 155 to 150℃.

Features

40T03GP features: (1)Simple Drive Requirement; (2)Low Gate Charge ; (3)Fast Switching; (4)RoHS Compliant.

Diagrams

40T03GP block diagram
